ACE Adjustable Shock Absorber M 64x2, 50 mm Stroke - MA6450EUM-HT
ACE adjustable industrial shock absorber with M 64x2 body thread and 50 mm stroke rated for up to 2275 Nm per stroke, 146000 Nm/h continuous, effective mass 220 - 50000 kg, operating temperature -12°C to max. +66°C (10 to +151 °F). Damping is tunable on-absorber to the actual mass and impact velocity. Used as an end-of-stroke buffer on heavy machine axes, cranes, hoists, transfer systems, and conveyor end stops where high kinetic energy must be absorbed safely.
- Precio normal
- $1,185.37 USD
Solo vendemos a empresas registradas
Descripción
ACE adjustable industrial shock absorber with M 64x2 body thread and 50 mm stroke rated for up to 2275 Nm per stroke, 146000 Nm/h continuous, effective mass 220 - 50000 kg, operating temperature -12°C to max. +66°C (10 to +151 °F). Damping is tunable on-absorber to the actual mass and impact velocity. Used as an end-of-stroke buffer on heavy machine axes, cranes, hoists, transfer systems, and conveyor end stops where high kinetic energy must be absorbed safely.
Pros:
- Tunable damping across 220–50000 kg, so each cycle ends at the lowest reaction force
- Rated 2275 Nm/stroke, 146000 Nm/h on a compact M 64x2 threaded body, 50 mm stroke
- Self-returning piston with integrated limit stop, no external return spring needed
Cons:
- Requires re-tuning when mass or impact velocity changes
- Operating range -12 to +66 °C (10 to +151 °F); derate or pick another series outside it
- Free-falling vertical loads need a separate energy calculation
